Product Details:
|
| Inveter: | VVVF Speed Controll | Energy Saving: | Home Lift Only 1 Kw With LED Light |
|---|---|---|---|
| Long Warranty: | 1-years Warranty | ARD: | 1 Unit 2-15kw |
| Affordable Price: | With High Quality First,factory Pricing | Customizable: | Following Client's For Decorative Materials |
| High Light: | ARD automatic rescue device elevator,15kw automatic rescue device elevator,3m/s 13 passenger lift |
||
ARD Automatic Rescue Device Elevator 3m/s 13 Passenger Lift
The ARD elevator (Automatic Rescue Device). is the newest generation of emergency rescue device for elevator system return of cabinet to the nearest floor or bottom floor and opens the door safely. It is manufactured at our vendor’s end using optimum grade components and cutting-edge techniques in compliance with set industry norms.
| Machine room panoramic lift standard parameter list: | ||||||||
| Loading capacity | Speed | Standard cabin size | Standard shaft size | Pit depth | Overhead | |||
| (kg) | Persons | (m/s) | Width | Depth | Width | Depth | (mm) | (mm) |
| (mm) | (mm) | (mm) | (mm) | |||||
| 630 | 8 | 1.0~2.5 | 1300 | 1200 | 1800 | 1800 | 1500 | 4200 |
| 800 | 10 | 1.0~2.5 | 1400 | 1350 | 1900 | 2000 | 1500 | 4200 |
| 1000 | 13 | 1.0~2.5 | 1600 | 1400 | 2100 | 2100 | 1500 | 4200 |
| 1350 | 18 | 1.0~2.5 | 1900 | 1600 | 2400 | 2300 | 1500 | 4200 |
| 1600 | 21 | 1.0~2.5 | 2000 | 1700 | 2500 | 2400 | 1500 | 4200 |
Function :
Man-machine interface
Micro-touch button for car call and hall call
Floor and direction indicator inside car
Floor and direction indicator
Emergency function
Emergency car lighting
Inching running
Five way intercom
Bell
Fire emergency return
Energy-saving function
Car ventilation, light automatic shut off
Remote shut-off
Option Function :
Emergency function
Leveling when power failure
Travel function
Anti-nuisance
Open the door in advance
Direct parking
Group control function
Duplex control
On-duty peak service
Door open time extending
FAQ
Why do you choose FUJI ELEVATOR?
1. We have the brand advantages, fuji elevator establish 1987 years .
We are the most professional elevator supplier in Japan and German.
2. The Good service with top quality world-wide network
3. We arrange trained engineering staff provides the customers with perfect services.
4. Our price are very competitive
After Sale Support
Installation Support :
1. Document Support : The complete documents including Installation manual will be delivered along with the elevator in the container.
2. Technical Support : Remote technical support is available via email, whatsapp, skype and etc If necessary ,a techincian will be sent to assist you on the jobsite
3. Spare parts support : We will provide you the free spare parts delivered along with the container.
4. Maintenance Support : If any parts get damaged due to quality issue within 12 months after B/L date. We will send new replacement once confirmed.
Our Services:
1) Customers` Design ,Size,Color&Logo are accepted.
2) With15years professional manufacture experience
3) Prompt Delivery&Competitive Price
4) Main markets:Middle East, Europe, North America, Africa,Southeast Asia.
After-sales service:
1. We provide the technical support for whole life of our machines.
2. If buyers need the technician to go abroad ,we will arrange the technician,
but the buyers should take all the cost,including visa,roundtripticket etc.
