10 Persons Passenger Elevator CNAS Stainless Steel Lift Cabin

Certification
China FUJI through (GUANGDONG) Elevator Group Co., Ltd certification
China FUJI through (GUANGDONG) Elevator Group Co., Ltd certification
I'm Online Chat Now

10 Persons Passenger Elevator CNAS Stainless Steel Lift Cabin

10 Persons Passenger Elevator CNAS Stainless Steel Lift Cabin
10 Persons Passenger Elevator CNAS Stainless Steel Lift Cabin 10 Persons Passenger Elevator CNAS Stainless Steel Lift Cabin 10 Persons Passenger Elevator CNAS Stainless Steel Lift Cabin

Large Image :  10 Persons Passenger Elevator CNAS Stainless Steel Lift Cabin

Product Details:
Place of Origin: CHINA
Brand Name: GUANGDONG fuji
Certification: ICP 3A CE TUV IAF EACC ISO CNAS
Model Number: STD-015
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Factory price
Packaging Details: SEASHIPPING
Delivery Time: 1 MONTH
Payment Terms: T/T, L/C, Western Union
Supply Ability: 100UNITS PER MONTH

10 Persons Passenger Elevator CNAS Stainless Steel Lift Cabin

Description
Capacity: 6-20persons Energy Saving: Home Lift Only 1 Kw With LED Light
ARD: 1 Unit 2-15kw Affordable Price: With High Quality First,factory Pricing
Customizable: Following Client's For Decorative Materials
High Light:

Wooden wall Passenger Elevator

,

10 persons Passenger Elevator

,

CNAS stainless steel lift cabin

10 Persons Passenger Elevator CNAS Stainless Steel Lift Cabin



Small machine room passenger elevator



Save building space, expand building space utilization, make the operation more sensitive and reliable, make the building more elegant and beautiful, small machine room elevator, using rare earth material permanent magnet synchronous gearless traction machine and elevator special thin control cabinet, reducing 25mm The height of the machine room makes the area of the machine room consistent with the area of the hoistway.



Passenger elevator without machine room



Adhering to the energy-saving and high-efficiency advantages of machine-room-less elevators, the product has been upgraded in terms of customer experience, civil construction costs, installation and maintenance convenience, etc., using efficient host and control systems, which have faster speeds and better riding comfort. Higher security.



Machine room panoramic lift standard parameter list:
Loading capacity Speed Standard cabin size Standard shaft size Pit depth Overhead
(kg) Persons (m/s) Width Depth Width Depth (mm) (mm)
(mm) (mm) (mm) (mm)
630 8 1.0~2.5 1300 1200 1800 1800 1500 4200
800 10 1.0~2.5 1400 1350 1900 2000 1500 4200
1000 13 1.0~2.5 1600 1400 2100 2100 1500 4200
1350 18 1.0~2.5 1900 1600 2400 2300 1500 4200
1600 21 1.0~2.5 2000 1700 2500 2400 1500 4200



Quick Details



Warranty: 1 Year, 13 months

After-sale Service: Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement

Project Solution Capability:

graphic design, 3D model design, total solution for projects, Cross Categories Consolidation, Others

Application: Office Building

Design Style: Modern

Place of Origin: China

Brand Name: Guangdong Fuji

Model Number: Fuji-011

Usage: Residential Elevators

Drive Type: AC

Elevator Type: Passenger Elevators

Product name: VVVF drive FUJI passenger elevator

Certification: ISO/CE/

Speed: 1.0, 1.5, 1.75, 2.0, 2.5, 3.0, 4.0, 6.0m/s
