PM Gearless Traction MRL Elevator VVVF Inveter 220V MRL Home Lift

PM Gearless Traction MRL Elevator VVVF Inveter 220V MRL Home Lift
PM Gearless Traction MRL Elevator VVVF Inveter 220V MRL Home Lift PM Gearless Traction MRL Elevator VVVF Inveter 220V MRL Home Lift PM Gearless Traction MRL Elevator VVVF Inveter 220V MRL Home Lift PM Gearless Traction MRL Elevator VVVF Inveter 220V MRL Home Lift PM Gearless Traction MRL Elevator VVVF Inveter 220V MRL Home Lift

Large Image :  PM Gearless Traction MRL Elevator VVVF Inveter 220V MRL Home Lift

Product Details:
Place of Origin: CHINA
Brand Name: GD-Fuji
Certification: CE TIV 3A
Model Number: FJ-ML-001
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 12000-15000USD
Packaging Details: SEA SHIPPING
Delivery Time: 15DAYS
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30/WEEK

PM Gearless Traction MRL Elevator VVVF Inveter 220V MRL Home Lift

Gearless Motor: VVVF Driving Power: AC 220V 380V Singel/3 Phase
Voice Stop: With Speaker LED Displayer: 7 Inches
High Light:

VVVF inveter MRL Elevator


PM gearless traction MRL Elevator


220V mrl home lift

Full set inveter Control Machine Roomless Home Elevators with PM gearless drive


Product Features

  • Machine roomless design saves construction cost
  • Specially designed car sling with 2:1 roping
  • VVV drive, micro-controller, smooth and comfortable
  • 220V or 380V specialized motor which is more professional and effective
  • Special traction machine bracket fixed on guide rail that assures no pressure on shaft wall
  • Excellent at energy saving with simple outer looking and vibration proof


Multiple considerations for super carrying


Guangdong Fuji Freight Elevator uses a fully computerized modular elevator dedicated control system, efficient and reliable drive mode, and a soft and sensitive VVVF variable frequency door operator, which makes it easy to carry and respond freely under various working conditions; high-strength sedan The structure of the compartment, the anti-collision strip and the light curtain door can meet various cargo purposes and use different building structures, making more load-bearing and heavy lifting more capable. Create a new concept of cargo transportation.


Large opening distance


It adopts diversified door opening methods, and the door width is large, which is convenient for the in and out of large goods.


Light curtain protection


A light curtain protection barrier is formed at the entrance of the elevator, which can react sensitively to any object that enters its detection range, effectively protecting the safety of people and goods.


strong and sturdy


The car chassis is made of high-strength profiles, and the specially reinforced design of the car chassis is durable.



Key Components


1. Elevator Traction Machines

Special purpose PM gearless traction machine for villa elevator, the motor has Ф240 wheel diameter and its unique structure lowered the total height of the motor and reduces the overhead requirement.


2. Elevator Door System

Adopts VVVF technology and it ensures noiseless and smooth operation.


3. Control System adopts Full Serial Villa Elevator Controller

Adopts FPGA+DSP control platform with strong data processing capacity, anti-interference design, safety protections for both elevator control and drive system control, which ensure the super reliability and stability of our home elevator.

2.2kw low power is specially designed for villa elevator.


4. Elevator Safety Components

Speed governor, safety gear, oil buffer, guide shoe and rope brake ,all safety components parts are carefully selected from top-grade professional factories, fully comply with GB7588-2003 standard ( equivalent to the EN81-1: 1998 standard), featuring professional product design, high quality, passing national type testing certification.


Function for Residential Home Elevators and villa elevator

B Standard Function O Optional Function
Safety Features
Fault Detection
B Motor Overheating Protection B Forbidden Switch of Door Opening
B Subsection Inspection of Safety Circuit B Speed Governor Tension Safety Contacts
B Main Power Switch Box B Car Door Contacts
B Running Hours Cumulating B

Car Lighting Main Switch Box Main Fuse

Inside of Controller Box

B Car Positioning Switch B Pit Brace Rod Contacts
B Car Emergency Stop Switch--Car Top B Car Top Brace Rod Contacts
B Car Emergency Stop Switch--Pit B Electrical Brake Releasing Function
B Safety Gear Safety Contact B Car Emergency Light
B Speed Governor Safety Contacts O ARD--- Automatic Rescue Device
B Main Switch Inside Controller Box B Emergency Call(One Digit Dial Telephone)
Information Function Comfort Functions
Landing Information Display Entering & Exit Cabin
B Landing Call Indicating Light B Door Opening Button
O Travelling Direction Indicators at Every Floor, Floor Number Display B Door Closing Button
B Light Curtain
Inside Cabin Information Display Comfortable Running
B COP Call Indicating Light B Car Lighting
B Overload Symbol& Buzzer B Fan
B Car Position Display O Background Music
B Travelling Direction Indicators O Voice Announcer
CCTV Camera Misusage Protection
B Door Zone Indicating Light B Calling Cancellation by 2 Times Button Pressing on COP
B Running Times Accumulating B Viscous Button Monitoring
B Normal Fault Signal B Opposite Direction Calling on COP
Control Functions
Prior/Special Service Functions / Special Functions
B Landing Call Forbidden B Testing Running
B Auto Door O Functions for Disabled (Braille Button, Voice Announcer)
B Door Opening and Closing Timing at Each Floor, Unified Regulation B Re-Opening Door When Landing Call
B Inspection Running O Through Opening Door
B Emergency Returning O Optional Door is Available (If It is Through Opening)

Residential Home Elevators and villa elevator, whether in terms of quality or decoration, is dedicated to creating a permanent, graceful enjoyment in life. Special inverter systems control the running position, upgrading the comfort feeling all-sided. With the advanced permanent magnet synchronous technology adopted, the advantage of energy-saving is maintained and the elevator is more rationally arranged in a concise way. It is compact and economic elevator for the villa-like and multistoried buildings, and ideal lifting vehicle for old man, patient and disabled people.
