Product Details:
|
| Controll Way: | VVVF Inveter | Power: | 3phase 380VAC |
|---|---|---|---|
| Floor: | Deck Steel | Speed: | 0.4-1.0m/s |
| High Light: | 1.0m/s Freight Elevators,VVVF Control Freight Elevators,2000kg lift with machine room |
||
1.0m/s Freight Elevators VVVF Control 2000KG Lift With Machine Room
GuangDong fuji elevator company adheres to the advanced international elevator management mode and innovative fruits in technical field.It actively introduces the first-class elevator manufacture equipment.It establishes the perfect and superior product system.It takes the management ideas of "since,creditable,promise-keeping,cooperation and double-win".it is engaged in sci-tech innovation.
It owns multiple original core technologies.At present,the products cover passenger elevator(small machine room,traction type villa elevator),freight elevator.automobile elevator,escalator,moving walk series etc.According to the user's requirements, it executes the market operation mode which integrates the manufacture,sales,installation,repair and maintenance into one.It design and produces different kinds of plural elevators as per the user's actual.
| Machine room panoramic lift standard parameter list: | ||||||||
| Loading capacity | Speed | Standard cabin size | Standard shaft size | Pit depth | Overhead | |||
| (kg) | Persons | (m/s) | Width | Depth | Width | Depth | (mm) | (mm) |
| (mm) | (mm) | (mm) | (mm) | |||||
| 630 | 8 | 1.0~2.5 | 1300 | 1200 | 1800 | 1800 | 1500 | 4200 |
| 800 | 10 | 1.0~2.5 | 1400 | 1350 | 1900 | 2000 | 1500 | 4200 |
| 1000 | 13 | 1.0~2.5 | 1600 | 1400 | 2100 | 2100 | 1500 | 4200 |
| 1350 | 18 | 1.0~2.5 | 1900 | 1600 | 2400 | 2300 | 1500 | 4200 |
| 1600 | 21 | 1.0~2.5 | 2000 | 1700 | 2500 | 2400 | 1500 | 4200 |
| Load capacity | 2000kg-5000kg |
| speed | 0.5m/s-2m/s |
| Drive type | AV ,VVVF, |
| Machine room type | machine room&machine roomless |
| Control | Full collection |
| Control System | Monarch Nice3000 |
| Material | spray steel plate/hairline SS/mirror SS/mirror etched SS/glass |
| Run Type | Simplex/parallel/group control |
| Warranty | 1year |
