Product Details:
|
| Cabin: | 304 Stailess Mirror Etching | Power: | AC220/380V |
|---|---|---|---|
| Capicity: | 6-8p | Speed: | 1.0-2.5m/s |
| Roof: | Stainless Steel Led Light | ||
| High Light: | Stainless steel 304 Residential Elevators,Vvvf drive Residential Elevators,2.5m/s small elevators for homes |
||
Low Noiseina Vvvf Machine Room Office Buildin Passenger Elevatoror etching residential elevator lift
Key Components
1. Elevator Traction Machines
Special purpose PM gearless traction machine for villa elevator, the motor has Ф240 wheel diameter and its unique structure lowered the total height of the motor and reduces the overhead requirement.
2. Elevator Door System
Adopts VVVF technology and it ensures noiseless and smooth operation.
3. Control System adopts Full Serial Villa Elevator Controller
Adopts FPGA+DSP control platform with strong data processing capacity, anti-interference design, safety protections for both elevator control and drive system control, which ensure the super reliability and stability of our home elevator.
2.2kw low power is specially designed for villa elevator.
4. Elevator Safety Components
Speed governor, safety gear, oil buffer, guide shoe and rope brake ,all safety components parts are carefully selected from top-grade professional factories, fully comply with GB7588-2003 standard ( equivalent to the EN81-1: 1998 standard), featuring professional product design, high quality, passing national type testing certification.
|
Load(kg) |
Speed (m/s) |
Control mode |
Internal car size (mm) |
Door size (mm) |
Hoistway(mm) |
Generator room with one elevator (mm) |
Generator room with two elevator (mm) |
||||||||||
|
C.W |
C.D |
C.H |
D.H |
H.W |
H.W |
H.D |
P.H |
HR.H |
MR.W |
MR.D |
MR.H |
MR.W |
MR.D |
MR.H |
|||
|
450 |
1 |
VVVF |
1100 |
1000 |
2500 |
800 |
2100 |
1850 |
1700 |
1500 |
4500 |
2500 |
3300 |
2500 |
4500 |
3330 |
2500 |
|
1.75 |
1700 |
4800 |
|||||||||||||||
|
630 |
1 |
1400 |
1100 |
2500 |
800 |
2100 |
2000 |
1800 |
1500 |
4500 |
2500 |
3300 |
2500 |
4500 |
3330 |
2500 |
|
|
1.75 |
1700 |
4800 |
|||||||||||||||
|
800 |
1 |
1400 |
1350 |
2500 |
800 |
2100 |
2000 |
2000 |
1500 |
4500 |
2600 |
3650 |
2500 |
4600 |
3650 |
2500 |
|
|
1.75 |
1700 |
4800 |
|||||||||||||||
|
2 |
1900 |
5100 |
|||||||||||||||
|
2.5 |
2100 |
5300 |
|||||||||||||||
|
1000 |
1 |
1600 |
1500 |
2500 |
900 |
2100 |
2200 |
2200 |
1500 |
4500 |
2800 |
3850 |
2500 |
5600 |
3850 |
2500 |
|
|
1.75 |
1700 |
4800 |
|||||||||||||||
|
2 |
1900 |
5100 |
|||||||||||||||
|
2.5 |
2100 |
5300 |
|||||||||||||||
|
1150 |
1 |
1800 |
1500 |
2500 |
1100 |
2100 |
2400 |
2200 |
1500 |
4500 |
3200 |
3850 |
2500 |
6400 |
3750 |
2500 |
|
|
1.75 |
1700 |
4800 |
|||||||||||||||
|
2 |
1900 |
5100 |
|||||||||||||||
|
2.5 |
2100 |
5300 |
|||||||||||||||
|
1350 |
1 |
1900 |
1600 |
2500 |
1100 |
2100 |
2500 |
2300 |
1500 |
4500 |
3250 |
3950 |
2500 |
6500 |
3950 |
2500 |
|
|
1.75 |
1700 |
4800 |
|||||||||||||||
|
2 |
1900 |
5100 |
|||||||||||||||
|
2.5 |
2100 |
5300 |
|||||||||||||||
|
1600 |
1 |
2000 |
1750 |
2500 |
1100 |
2100 |
2600 |
2500 |
1500 |
4500 |
3250 |
4150 |
2500 |
6500 |
4150 |
2500 |
|
|
1.75 |
1700 |
4800 |
|||||||||||||||
|
2 |
1900 |
5100 |
|||||||||||||||
|
2.5 |
2100 |
5300 |
|||||||||||||||
Basic Info.
Model NO.
Passenger Elevator
Elevator Door
Center Opening Door
Door Knife
Single
Deceleration Device
With Deceleration Device
Attendant
Without Attendant
Certification
ISO9001:2008,Das,Iaf,SGS,Ukas
Drive Control System
Step As380 or Monarch Nice3000 New
Color Standard Series
Customized
Communication Mode
Serial,Parallel
Warranty Period
18 Months
Drive Type
AC
Load Capacity
250kgs/320kgs/400kgs
Traction Machine
Geared,Gearless Traction Machine
Brand Name
FUJI
Elevator Type
Passenger Elevator
Cabin
Customers′ Specific Requirements
Model Number
Passenger Elevator
Door Control System
Vvvf
Package
Wooden Box
Material
Metal
Trademark
FUJI
Transport Package
Standard Export Package
Specification
250kg-500kg
Origin
China
HS Code
842810109
Contact Person: Mr. Feng
Tel: +13928523665
